PMC Endpoint Manager manages NComputing devices over local and wide-area networks, including those behind firewalls and NAT-routers. Features such as automatic discovery, check-in, flexible configuration, remote firmware updates, and provisioning of new devices make deployment easy. Additionally,  you can manage all your devices from a web browser.

The example below illustrates the network deployment topology, showing how PMC manages devices on both local and WAN networks (including devices behind the NAT-routers).

​

A computer screen shot of a computerDescription automatically generated



There is a Company Network with PMC located in the company’s Datacenter. PMC’s internal IP is 10.220.25.11 and it uses the default TCP port 443. The router connecting the Datacenter with the Internet has the 55.124.17.81 public IP on its Internet interface. Let’s assume that the public DNS resolves the ‘some.external.fqdn’ FQDN to the 55.124.17.81 public IP. This router is configured to forward (translate) the TCP traffic arriving from the Internet on the 11443 port of the public IP (55.124.17.81:11443) to the PMC’s internal IP and port (10.220.25.11:443).



There are three external sites, each one with a NAT router translating the internal (private) IPs to some public IPs when the devices establish connections to Internet locations:

Site

Internal/private/local

Subnet IP address

Public IP

(visible in PMC)

External site 1

172.16.18.0/24

13.8.3.21

External site 2

192.168.12.0/24

212.77.27.82

External site 3

10.0.5.0/24

72.163.4.17



The devices from all the three external sites can by configured to connect to PMC through any of following addresses or URLs:



55.124.17.81:11443

some.external.fqdn:11443

https://55.124.17.81:11443

https://some.external.fqdn:11443



All of them will work in the same way.


The devices from some internal subnet (10.100.45.0/24, inside the Company Network), can connect to PMC directly, without going through any NAT. PMC will see the devices under their original private/local/internal IPs. The internal devices should be configured to use PMC addresses or URLs like:

10.220.25.11

10.220.25.11:443

https://10.220.25.11

https://pmc.company.local   (assuming that internal DNS resolves ‘pmc.company.local’ to 10.220.25.11)



To restrict the PMC access for the devices or users, the ‘IP access restrictions’ feature of PMC 4.1.1 should be enabled in under Administration > System Settings.



The devices from allowed locations should by whitelisted by creating IP access rules:

Whitelisted location

IP access rule

External site 1

13.8.3.21/32

External site 2

212.77.27.82/32

External site 3

72.163.4.17/32

Internal device subnet

10.100.45.0/24



Similarly, the access for the PMC users can be restricted to specific locations only by creating the IP access rules for the user group members under Administration > User Management.
